New

Abyss 2

Make a splash at any event or production with this stunning LED effect light that simulates a multicolored water effect. Abyss 2 shines through any environment with or without fog and provides independent control of the ripples and color. A manual focus knob ensures proper focus at most distances and non-DMX control of most settings is available via the digital display or optional IRC-6 remote.

Highlights

  • Eye-catching, LED effect light simulates a multicolored water effect

  • Shines through any environment with or without fog

  • Independent control of ripples and color

  • Manual focus knob ensures proper focus at most distances

  • Non-DMX control of most settings via the digital display or optional IRC-6 remote

  • Save time running cables and extension cords by power linking multiple units

  • Fits best in the CHS-40 VIP Gear Bag

Specifications

  • DMX Channels: 3
  • DMX Connectors: 3-pin XLR
  • Colors: 5 + white, Rainbow scroll
  • Light Source: 1 LED 60 W, (2 A), 50,000 hours life expectancy.
  • PWM Frequency: 4K Hz
  • Coverage Angle: 60°
  • Illuminance: 5,010 lux @ 2 m
  • Power Linking: 7 units @ 120 V; 13 units @ 230 V
  • Input Voltage: 100 to 240 VAC, 50/60 Hz (auto-ranging)
  • Power and Current: 80 W, 1.1 A @ 120 V, 60 Hz
    74 W, 0.6 A @ 230 V, 50 Hz
  • Weight: 6.2 lb (2.8 kg)
  • Size: 8 x 7 x 6 in (203 x 178 x 152 mm)
  • Approvals: CE

What's Included

  • Abyss 2
  • Abyss 2
  • Power cord
  • Quick Reference Guide

Downloads
