Discontinued Since 2014

BEAMshot

Similar Product Available

You might also like:

LED Pinspot 2

BEAMshot is a unique, LED powered effect light that shoots an intense, ultra-narrow beam of light. Easily transform intense beams into a brilliant array by incorporating fog or haze into your event.

VIP Rewards Value: 50 Points



Highlights

  • Compact aerial effect light outshines the competition with narrow, razor-sharp beams

  • Build an impressive matrix or create runway effects using multiple fixtures

  • Change the color with the included 4-pack of gels

  • Achieve super-smooth LED fading with built-in dimming curves

  • Save time running cables and extension cords by power linking multiple units

  • Easily generate complex looks using ShowXpress™ Pixels (multiple fixtures required)

  • Trigger built-in automated programs in master/slave or DMX mode

  • Sound-activated programs dance to the beat of the music

  • Easily transport up to 8 units in the CHS-30 VIP Gear Bag

Specifications

  • DMX Channels:2 or 4
  • DMX Connectors:3-pin XLR
  • Light Source:1 LED (white) 6 W (1.5 A), 50,000 hours life expectancy
  • Strobe Rate:0 to 20 Hz
  • PWM Frequency:600 Hz
  • Beam Angle:
  • Illuminance:16,350 lux @ 2 m
  • Power Linking:62 units @ 120 V; 100 units @ 230 V
  • Input Voltage:100 to 240 VAC, 50/60 Hz (auto-ranging)
  • Power and Current:15 W, 0.1 A @ 120 V, 60 Hz
    19 W, 0.1 A @ 230 V, 50 Hz
  • Weight:1.4 lb (0.7 kg)
  • Dimensions:8.3 x 5.7 x 4.1 in (210 x 145 x 105 mm)
  • Approvals:CE

What's Included

  • BEAMshot
