COLORband T3 USB

COLORband T3 USB is a full-size LED strip light that functions as a chase effect, blinder or wall washer and features three zones of control to create amazing chasing effects. Control is easy with convenient access to multiple pre-programs with or without DMX, and sound-activated programs. The unit is D-Fi USB compatible for wireless master/slave or DMX control.  COLORband T3 USB includes multiple DMX personalities for a wide variety of programming styles and its silent operation makes it ideal for quiet applications. Fits best in the optional CHS-60 VIP Gear Bag.

Highlights

  • Full-size LED strip light functions as chase effect, blinder or wall washer

  • D-Fi USB compatibility for wireless Master/Slave or DMX control

  • 3 zones of control create amazing chasing effects

  • Convenient access to multiple pre-built programs with or without DMX

  • Includes multiple DMX personalities for a wide variety of programming styles

  • Nearly eliminate multicolor shadows with high-power, tri-color LEDs

  • Ideal for quiet applications due to silent operation and no moving parts

  • Sound-activated programs dance to the beat of the music

  • Easily transports in the optional CHS-60 VIP Gear Bag

Specifications

  • DMX Channels: 3, 6, 8, 9 or 14
  • DMX Connectors: 3-pin XLR
  • Light Source: 12 LEDs (tri-color RGB) 3 W (700 mA), 50,000 hours life expectancy
  • Strobe Rate: 0 to 26 Hz
  • PWM Frequency: 1.2 kHz
  • Beam Angle: 27°
  • Field Angle: 45°
  • Coverage Angle: 45°
  • Illuminance: 1,760 lux @ 2 m
  • Power Linking: 21 units @ 120 V; 38 units @ 230 V
  • Input Voltage: 100 to 240 VAC, 50/60 Hz (auto-ranging)
  • Power and Current: 27 W, 0.4 A @ 120 V, 60 Hz
    26 W, 0.2 A @ 230 V, 50 Hz
  • Weight: 5.8 lb (2.7 kg)
  • Size: 38.9 x 2 x 6.2 in (987 x 49 x 157 mm)
  • Approvals: CE, MET
  • Optional Controllers: IRC-6, D-Fi USB

What's Included

  • COLORband T3 USB
  • Power cord
  • Hanging bracket with mounting hardware
  • Warranty card
  • Quick Reference Guide
