EZLink Par Q6BT ILS

EZLink Par Q6BT ILS is a battery-operated, quad-color (RGBA) LED Par with built-in ILS compatibility for use in the ILS ecosystem that makes creating coordinated light shows across an unlimited number of different fixture types quick and easy. Bluetooth® wireless technology is also on board so you can control EZLink Par Q6BT ILS directly from a smart phone or tablet without any additional hardware. Plus, EZLink Par Q6BT ILS has D-Fi USB compatibility for wireless lead/follower or DMX control. You can generate a broad spectrum of colors and achieve natural-looking color temperatures with punchy amber LEDs and generate eye-catching effects with sound-activated and automated programs.

Highlights

  • 100% TRUE wireless, battery-operated, quad-color (RGBA) LED Par with built-in Bluetooth® wireless technology

  • ILS compatibility for use in the ILS ecosystem

  • D-Fi USB compatibility for wireless master/slave or DMX control

  • Control directly from a smart phone or tablet without any additional hardware

  • Convenient, wireless non-DMX control using the IRC-6 remote

  • Generate a broad spectrum of colors and achieve natural-looking color temperatures with punchy amber LEDs

  • Generate eye-catching effects with sound-activated and automated programs

  • Fits best in the CHS-40 VIP Gear Bag

Specifications

  • DMX Channels:4 or 8
  • DMX Connectors:3-pin XLR
  • Max Unobstructed Distance:150 ft (45.7 m)
  • Light Source:6 LEDs (quad-color RGBA) 3 W, 1 A, 50,000 hours life expectancy
  • Strobe Rate:0 to 25 Hz
  • Beam Angle:16°
  • Field Angle:30°
  • Maximum Run Time:
    All on: up to 8 hours
    Single color: up to 20 hours
  • Recharge Time:4 hours
  • Operating Frequency:2.4 GHz
  • Illuminance:1,587 lux @ 2 m
  • Power Linking:17 units @ 120 V; 31 units @ 230 V
  • Input Voltage:100 to 240 VAC, 50/60 Hz (auto-ranging)
  • Power and Current:
    33 W, 0.5 A @ 120 V, 60 Hz
    32 W, 0.3 A @ 230 V, 50 Hz
  • Weight:3.8 lb (1.7 kg)
  • Size:8 x 9.6 x 3.4 in (207 x 244 x 86 mm)
  • Approvals:CE, UKCA, RoHS, FCC
  • Cable Length: 5 ft (1.524 m)
  • Bracket Mounting Hole: 13 mm
  • Optional Controllers: IRC6, BTAir
  • Bluetooth Version: 4.2

What's Included

  • EZLink Par Q6BT ILS
  • EZLink Par Q6BT ILS
  • Power cord
  • Quick Reference Guide
