EZLink Wedge Q3BT ILS

EZLink Wedge Q3BT ILS is a 100% TRUE wireless, battery-operated, quad-color (RGBA) LED wash light solution. Its wedge-shaped design makes it the ideal fixture for venue corners, Trusst Goal Post and Arch Kit truss systems. Enjoy a wide range of control options including the IRC-6 remote, ILS, Bluetooth, and DMX. Generate a broad spectrum of colors and achieve natural-looking color temperatures throughout your event thanks to punchy amber LEDs.

*includes Mexico & Canada

Highlights

  • 100% TRUE wireless, battery-operated, quad-color (RGBA) LED wash light with built-in Bluetooth® wireless technology

  • ILS compatibility for use in the ILS ecosystem

  • Control directly from a smart phone or tablet without any additional hardware

  • Convenient, wireless non-DMX control using the IRC-6 remote

  • The wedge-shaped design makes it fit perfectly inside TRUSST® Goal Post and Arch Kit truss systems

  • Generate a broad spectrum of colors and achi66.8eve natural-looking color temperatures with punchy amber LEDs

  • Attaches to truss without the need for a bracket, using M10 or M12 threaded rig points

  • Save time running cables and extension cords by power linking multiple units

Specifications

  • DMX Channels:4 or 8
  • DMX Connectors:3-Pin XLR
  • Light Source:3 LEDs (quad-color RGBA) 5 W, (1.4 A), 50,000 hours life expectancy
  • Strobe Rate:0 to 20 Hz
  • Beam Angle:13°
  • Field Angle:25°
  • Recharge Time:5 hours
  • Illuminance:1,400 lux @ 2 m
  • Power Linking:16 units @ 120 V; 23 units @ 230 V
  • Input Voltage:100 to 240 VAC, 50/60 Hz (auto-ranging)
  • Weight:2 lb (0.9 kg)
  • Size:4.3 x 4.3 x 6.8 in (109 x 109 x 171 mm)
  • Approvals:CE, RoHS, UKCA, FC
  • Optional Controllers: IRC-6
  • Maximum Run Time (all on) (single color): up to 20 hours: up to 9 hours Maximum Run Time
  • Bracket Mounting Hole: 13 mm
  • Maximum Run Time (all on):: up to 9 hours
  • Maximum Run Time (single color):: up to 20 hours
  • Power and Current: 30 W, 0.5 A @ 120 V, 60 Hz
  • Power and Current: 28 W, 0.3 A @ 230 V, 50 Hz
  • Input Voltage: 100 to 240 VAC, 50/60 Hz (auto-ranging)

What's Included

  • EZLink Wedge Q3BT ILS
  • EZLink Wedge Q3BT ILS
  • Power cord
  • Quick Reference Guide
Save & Print

Downloads

EZLink Wedge Q3BT ILS - Quick Reference Guide
