Discontinued Since 2015

Freedom Strip Mini RGBA

Freedom Strip Mini RGBA, the next generation in the 100% true wireless Freedom series, features 10mm LEDs for a tighter beam, battery power and an integrated D-Fi 2.4GHz wireless DMX system. The addition of amber LEDs provides an increased color spectrum, while a lightweight, rechargeable lithium-ion battery powers the unit for up to 8 hours. For simple operation when wireless DMX isn’t needed, easy “point and shoot” operation is achieved with the IRC (Infrared Remote Control). Freedom Strip Mini RGBA works in master/slave mode with other Freedom fixtures, COLORstrip, and COLORstrip Mini.

Highlights

  • 100% TRUE wireless, battery-operated RGBA LED strip light with built-in D-Fi™ 2.4 GHz wireless control

  • Create rich colors and pastels with amber LEDs

  • Master/slave wirelessly using D-Fi 2.4 GHz with other Freedom™ fixtures for a coordinated light show.

  • Create coordinated light shows by linking other Freedom™ Par RGBA, Freedom™ Strip Mini and Freedom™

  • Par fixtures in master/slave mode

  • Convenient wireless control using D-Fi™ 2.4 GHz or IRC remote

  • Send and receive wireless DMX signals with the built-in D-Fi™ 2.4 GHz transceiver

  • Set up and tear down in a fraction of the time by eliminating the need for DMX or power cables

  • Extended run time of up to 20 hours with the rechargeable, lithium-ion battery

  • Achieve pristine color mixing with 200 RGBA LEDs (50 red, 50 green, 50 blue and 50 amber)

  • Wireless control of sectional, eye-catching chase effects via DMX or IRC remote

  • Extend the battery’s lifespan with built-in discharge protection

  • Shine light where it is needed using the adjustable tilt

  • Access built-in, eye-catching automated and sound-activated programs via wireless DMX, IRC remote or master/slave mode

  • Functions as a D-Fi™ 2.4 GHz transmitter or receiver to transmit wireless DMX to any D-Fi™ 2.4 GHz receiver fixture including Freedom™ Par and Freedom™ Strip Mini

  • IRC remote provides wireless non-DMX control

  • Easily connects to Freedom™ Par and Freedom™ Strip Mini using backward compatibility mode

  • Enhance light shows with adjustable electronic strobe and dimmer effects

  • Easily charge, store and transport your fixtures from gig to gig in the Freedom™ Charge S.

Specifications

  • DMX Channels: 4 or 5
  • DMX Connectors: 3-pin XLR
  • Light Source: 200 LEDs (50 red, 50 green, 50 blue, 50 amber) 0.25 W (20 mA) 100,000 hours life expectancy
  • Beam Angle: 13°
  • Field Angle: 24°
  • Maximum Run Time: (all on): up to 8 hours
    (single color): up to 20 hours
  • Recharge Time: 6 hours
  • Operating Frequency: 2.433 to 2.481 GHz
  • Illuminance: 1,370 lux @ 2 m
  • Power Linking: 16 units @ 120 V; 25 units @ 230 V
  • Input Voltage: 100 to 240 VAC, 50/60 Hz (auto-ranging)
  • Power and Current: 71 W, 0.6 A @ 120 V, 60Hz
    94 W, 0.4 A @ 230 V, 50Hz
  • Weight: 7.6 lb (3.4 kg)
  • Size: 20 x 3 x 8.3 in (510 x 78 x 210 mm)
  • Approvals: CE, FCC
  • Included Controllers: IRC

What's Included

  • Freedom Strip Mini RGBA
