Gobo Zoom 2

Thrill event guests with customized logos, icons and other designs with Gobo Zoom 2, a high-powered custom gobo projector with a punchy 70 W LED. Proper positioning of gobos is easy with an innovative manual rotation knob that allows fast indexing without gobo removal. Gobo Zoom 2 comes with 10 popular holiday gobos and manual zoom for short-throw or long-throw applications, making it versatile and convenient. The convenience doesn’t stop there. Most functions are accessible with an optional IRC-6 remote and set-up time can be reduced by power linking multiple units.

Highlights

  • High-powered custom gobo projector with a punchy 70 W LED

  • Innovative manual rotation knob allows fast indexing without gobo removal

  • Manual zoom for short-throw or long-throw applications

  • Includes 10 popular holiday gobos

  • Access most functions via the optional IRC-6 remote

  • Reduce set-up time by power linking multiple units

  • Fits best in the CHS-40 VIP gear bag

  • Includes 10 popular holiday gobos

Specifications

  • DMX Channels:1
  • DMX Connectors:3-pin XLR
  • Light Source:1 LED (cool white) 70 W, (3A), 50,000 hours life expectancy
  • PWM Frequency:4000 Hz
  • Illuminance:(21°): 8,030 lux @ 2 m
    (38°): 2,660 lux @ 2 m
  • Lumens: 2,894
  • Power Linking:7 units @ 120 V; 14 units @ 230 V
  • Input Voltage:100 to 240 VAC, 50/60 Hz (auto-ranging)
  • Power and Current:74 W, 1 A @ 120 V, 60 Hz
    72 W, 0.6 A @ 230 V, 50 Hz
  • Weight:5.8 lb (2.6 kg)
  • Size:13 x 6 x 5.7 in (330 x 150 x 145 mm)
  • Approvals:CE
  • Gobo Size (E): 37.3 mm outside, 22 mm image, 1 mm max thickness
  • Zoom Angle (manual): 21° to 38°
  • Bracket Mounting Hole: 13 mm
  • Optional Controllers: IRC

What's Included

  • Gobo Zoom 2
  • Gobo Zoom 2
  • Power cord
  • Quick Reference Guide
