Discontinued Since 2017

Intimidator Spot 355Z IRC

The Intimidator Spot 355Z IRC is a brilliantly bright moving-head light with motorized focus and zoom for crisp gobo and beam changing effects. Seven already installed gobos plus the wedding 6-pack give you plenty of options for creating a unique look for every event. Master/Slave mode lets you create a beautiful light show quickly and easily. Built-in automatic programs along with move-in-black capability make programming with a CHAUVET® DJ DMX controller as easy as can be.

Highlights

  • Exceptionally bright, 90 W LED moving head spot designed for large events

  • Motorized zoom for short-throw or long-throw applications

  • Beams always remain on the dance floor using the built-in, innovative Totem mode

  • Simple navigation and full text readout with the high-contrast, full-color LCD display

  • Includes a FREE wedding-ready gobo pack that can be installed quickly and easily

  • Works with the IRC-6 for wireless control and triggering

  • Power link multiple units to save time running extension cords

  • Easy-access gobo door allows for quick gobo changes without opening the fixture

  • Emit crisp projections at almost any distance using the motorized focus

  • 3-facet rotating prism splits the beam for great effects and to cover a larger area

  • Built-in effect macros and move-in-black feature minimizes programming time

  • Activate built-in, automated and sound-activated programs, or control in DMX or Master/Slave mode

  • Project light where you want it with user-selectable pan and tilt ranges

  • Fits best in the CHS-50 VIP Gear Bag

Specifications

  • DMX Channels: 9 or 15
  • DMX Connectors: 3-pin XLR
  • Pan and Tilt: 540°/270°
  • Pan and Tilt Ranges: 540°, 360°, 180° pan/270°, 180°, 90° tilt
  • Colors: 8 + white, split colors, continuous scroll at variable speeds
  • Gobos: 7 + open (5 metal + 2 glass), rotating, interchangeable, indexing, slot-n-lock, continuous scroll at variable speeds
  • Light Source: 1 LED (white) 90 W (3.2 A), 50,000 hours life expectancy
  • Strobe Rate: 0 to 23 Hz
  • PWM Frequency: 2 kHz
  • Illuminance: (10°): 35,225 lux @ 2 m
    (17°): 11,800 lux @ 2 m
  • Power Linking: 4 units @ 120 V; 7 units @ 230 V
  • Input Voltage: 100 to 240 VAC, 50/60 Hz (auto-ranging)
  • Power and Current: 309 W, 3.2 A @ 120 V, 60 Hz
    283 W, 1.6 A @ 230 V, 50 Hz
  • Gobo Size: 24 mm outside, 20 mm image, 1.1 mm max thickness
  • Zoom Angle: (motorized): 10° to 17°
  • Weight: 27.4 lb (12.4 kg)
  • Size: 13.4 x 9.7 x 18 in (340 x 248 x 456 mm)
  • Approvals: CE
  • Series: Intimidator
  • Primary Use: DJ/Mobile, Bands/Stages, Events, Clubs, Party
  • Optional Controllers: IRC-6
  • Prism: 3-facet round, static, bidirectional rotation at variable speeds

What's Included

  • Intimidator Spot 355Z IRC
  • Power cord
  • Hanging bracket with mounting hardware
  • Warranty card
  • Quick Reference Guide

Downloads

Show & Tell

You’re the star! We want to see how you’re using CHAUVET DJ gear! Share your thoughts, experiences and photos of your events using this CHAUVET DJ product and find inspiration too!

  1. Incredible lighting fixtures
    -Clayton Nordhoff

    We UTILIZE our chauvet intimidator 355z’s in various lighting applications. The performance and versatility of the chauvet fixtures are second to none. Being a mobile entertainment company, we perform in hundred of venues each year. we are able to adjust our moving heads depending on the size of the venue and our setup layout.
