Intimidator Trio

The Intimidator Trio is an innovative, LED-powered moving head with beam, wash and effect features. It allows you to seamlessly change from a narrow beam to a wide wash with the motorized zoom. Its continuously rotating honeycomb delivers the excitement of an effect light and you can generate complex looks easily with built-in, eye-catching auto programs with zone control. The Intimidator Trio features built-in Totem mode that allows the beams to remain focused on the dance floor and coordinated master/slave programs for up to 4 fixtures gives an advanced look with no programming. You can set, save, and recall 1 scene directly from the full-color LCD display and convenient, wireless non-DMX control is at your fingertips using the optional IRC-6 remote. Save time running cables by power linking multiple units. Fits best in the CHS-50 VIP Gear Bag

Highlights

  • Innovative, LED-powered moving head with beam, wash and effect features

  • Seamlessly change from a narrow beam to a wide wash with the motorized zoom

  • Continuously rotating honeycomb delivers the excitement of an effect light

  • Generate complex looks easily with built-in, eye-catching auto programs with zone control

  • Built-in Totem mode allows the beams to remain focused on the dance floor

  • Coordinated master/slave programs for up to 4 fixtures gives an advanced look with no programming

  • Set, save, and recall 1 scene directly from the full-color LCD display

  • Convenient, wireless non-DMX control using the optional IRC-6 remote

  • Save time running cables by power linking multiple units

  • Fits best in the CHS-50 VIP Gear Bag

Specifications

  • DMX Channels: 15 or 30
  • DMX Connectors: 3-pin XLR
  • Pan and Tilt: 540°/270°
  • Pan and Tilt Ranges: 180°, 360°, 540° pan/90°, 180°, 270° tilt
  • Light Source: 6 LEDs (quad-color RGBW) 21 W (6.3 A), 50,000 hours life expectancy
  • Strobe Rate: 0 to 20 Hz
  • PWM Frequency: 1,200 Hz
  • Illuminance: (7°): 16,000 lux @ 2m
    (53°) : 1,350 lux @ 2 m
  • Power Linking: 4 units @ 120 V; 8 units @ 230 V
  • Input Voltage: 100 to 240 VAC, 50/60 Hz (auto-ranging)
  • Power and Current: 242 W, 2 A @ 120 V, 60 Hz
    232 W, 1 A @ 230 V, 50 Hz
  • Zoom Angle: 7° to 53°
  • Weight: 20 lb (9.2 kg)
  • Size: 10.9 x 10.9 x 15.2 in (278 x 278 x 386 mm)
  • Approvals: CE
  • Series: Intimidator
  • Primary Use: DJ/Mobile, Bands/Stages, Events, Clubs, Party
  • Optional Controllers: IRC-6

What's Included

  • Intimidator Trio
  • Power cord
  • Hanging bracket with mounting hardware
  • Warranty card
  • Quick Reference Guide
