Sentinel Spot Q60 ILS
The versatile Sentinel Spot Q60 ILS brings all the essential moving head features with no compromise and the added benefit of a Totem Mode that keeps all the action pointed at the dance floor. Project crisp gobos and saturated colors with its intense 60W RGBW LED. Built-in D-Fi makes wireless setups easy and ILS compatibility makes it a snap to instantly synchronize with a wide range of fixture types to create cutting-edge light shows. Smooth motion, consistent color and easy control, all in a compact size ideal for your next party gig.
Images & VIDEOS
Highlights
Cutting-edge moving head spot fitted with an intense RGBW color mixing LED
Built-in DFI transceiver communicates DMX or ILS signals wirelessly
Easy navigation and access to all functions directly from the full-color LCD display
ILS compatibility for use in the ILS ecosystem
Totem Mode keeps the moving head focused on the dance floor
Save time running cables and extension cords by power linking multiple units
Fits best in the CHS-40 VIP Gear Bag
Specifications
- DMX Channels:9 or 15
- DMX Connectors:3-pin XLR
- Pan and Tilt:540°/229°
- Pan and Tilt Ranges:180°, 360°, 540° pan/90°, 180°, 229° tilt
- Gobos:5 + open (6 glass), rotating, interchangeable, indexing, slot-n-lock, continuous scroll at variable speeds
- Light Source:1 LED (quad-color RGBW) 60 W, (4.4 A), 50,000 hours life expectancy
- Strobe Rate:0 to 20 Hz
- Beam Angle:12°
- Illuminance:8,687 lux @ 2 m
- Power Linking:7 units @ 120 V; 11 units @ 230 V
- Input Voltage:100 to 240 VAC, 50/60 Hz (auto-ranging)
- Power and Current:76 W, 1 A @ 120 V, 60 Hz
- Gobo Size:24 mm outside, 20 mm image, 1.1 mm max thickness
- Weight:9 lb (4.1 kg)
- Size: 8 x 5.9 x 13 in (204 x 150 x 332 mm)
- Approvals:CE, RoHS, FCC
- Power and Current: 76 W, 0.7 A @ 230 V, 50 Hz
- Optional Controllers: IRC-6, ILS Command
What's Included
- Sentinel Spot Q60 ILS
- Sentinel Spot Q60 ILS
- Power cord
- Hanging bracket
- Quick Reference Guide
