SlimBANK TRI-18
SlimBANK Tri-18 is a wide-area wash light fitted with 18 tri-color LEDs. It blends easily into traditional lighting rigs, thanks to built-in dimming curves; a fan-free design makes it ideal for use in noise-sensitive environments. Removable barn doors shield light from unwanted areas.
Images & VIDEOS
Highlights
Versatile tri-color LED wash light
Direct light where it’s needed using the included and removable barn doors
Generate complex looks easily with built-in, eye-catching auto programs with sectional control
Achieve smooth LED fading with built-in dimming curves
Ideal for sound-sensitive environments due to the radiant cooling design
Save time running extension cords by power linking multiple units
Easily transports in the CHS-40 VIP Gear Bag
Combine multiple units using the CBB-6 mounting bracket
Specifications
- DMX Channels: 3, 5, 9, or 13
- DMX Connectors: 3-pin XLR
- Light Source: 18 LEDs (tri-color RGB) 3 W (1,050 mA), 50,000 hours life expectancy
- Strobe Rate: 0 to 20 Hz
- PWM Frequency: 1,040 Hz
- Beam Angle: 17°
- Field Angle: 32°
- Illuminance: 5,450 lux @ 2 m
- Power Linking: 9 units @ 120 V; 16 units @ 230 V
- Input Voltage: 100 to 240 VAC, 50/60 Hz (auto-ranging)
- Power and Current: 105 W, 0.9 A @ 120 V 60 Hz 109 W, 0.5 A @ 230 V 50 Hz
- Weight: 7 lb (3.2 kg)
- Size: 15.3 x 7.7 x 7.4 in (389 x 197 x 187 mm)
- Approvals: CE
What's Included
- SlimBANK TRI-18
