SlimPAR H6 USB

SlimPAR H6 USB is a low-profile RGBAW+UV LED washlight with D-Fi USB compatibility for wireless master/slave or DMX control. It also works in sound-active mode.

Built-in dimming curves provide smooth LED fading, and the 6-in-1 LED technology generates a broad spectrum of natural looking colors. Precise colors can also be created with the built-in LED display. Point-and-shoot operation of static colors and automated programs is possible with the optional IRC-6 remote. Compact designed, it works as truss warmer. Easily transports in the optional CHS-30 VIP Gear Bag.

Highlights

  • Low-profile LED PAR with 6-in-1 LED technology (RGBAW+UV)

  • D-Fi USB compatibility for wireless Master/Slave or DMX control

  • Generate a broad spectrum of colors and achieve natural-looking color temperatures with 6-in-1 LED technology

  • Point-and-shoot operation of static colors and automated programs with the optional IRC-6 remote

  • Save time running cables and extension cords by power linking multiple units

  • Multiple control options include DMX, Master/Slave and Sound-Active modes

  • Create customized colors using the built-in LED display

  • Achieve smooth LED fading with built-in dimming curves

  • Flicker-free operation suitable for on-camera use

  • Easily transports in the optional CHS-30 VIP Gear Bag

  • Sleek and lightweight to easily fit inside sticks of TRUSST®

Specifications

  • DMX Channels: 6, 8 or 12
  • DMX Connectors: 3-pin XLR
  • Light Source: 6 LEDs (hex-color RGBAW+UV) 10 W (2.4 A), 50,000 hours life expectancy
  • Strobe Rate: 0 to 18 Hz
  • PWM Frequency: 1.2 kHz
  • Beam Angle: 23°
  • Field Angle: 41°
  • Illuminance: 747 lux @ 2 m
  • Power Linking: 20 units @ 120 V; 39 units @ 230 V
  • Input Voltage: 100 to 240 VAC, 50/60 Hz (auto-ranging)
  • Power and Current: 25 W, 0.4 A @ 120 V, 60 Hz
    23 W, 0.2 A @ 230 V, 50 Hz
  • Weight: 3.4 lb (1.6 kg)
  • Size: 8.3 x 3.6 x 9.6 in (211 x 91.5 x 244 mm)
  • Approvals: CE
  • Optional Controllers: IRC-6, D-Fi USB

What's Included

  • SlimPAR H6 USB
  • Power cord
  • Warranty card
  • Quick Reference Guide
  • User Manual
