Swarm Wash FX

Swarm Wash FX is a 4-in-1 LED effect fixture that combines an RGBAW rotating derby, RGB+UV wash, red/green laser, and a ring of white SMD strobes. Create an endless array of looks by individually controlling each effect via DMX and master/slave modes. Other features include automated and sound activated programs and a user-friendly menu structure. Multiple units can be power linked to save time running cables and extension cords. Fits best in the CHS-40 VIP Gear Bag.

Highlights

  • 4-in-1 LED light that combines an RGBAW rotating derby, RGB+UV wash, red/green laser, and a ring of white SMD strobes

  • Endless possible looks with individual control of each effect via DMX and Master/Slave modes

  • Improved menu structure for ease of use

  • Red and green laser beams project thousands of beams for maximum coverage

  • Quick set up with automatic and sound-activated programs

  • Control clutter and save time running cables and extension cords by power linking multiple units

  • Fits best inside the CHS-40 VIP Gear Bag

Specifications

  • DMX Channels: 2 or 18
  • DMX Connectors: 3-pin XLR
  • Light Source: (Swarm): 5 LEDs (1 red, 1 green, 1 blue, 1 amber, 1 white) 2 W (650 mA) 50,000 hours life expectancy
    (Wash): 8 LEDs (quad-color RGB+UV) 1.5 W (600 mA), 50,000 hours life expectancy
    (Strobe) 12 LEDs (white) 1 W (300 mA), 50,000 hours life expectancy
    (Laser): 650 nm/100 mW (red) laser diode, 532 nm/30 mW (green) laser diode
  • Strobe Rate: 0 to 20 Hz
  • Power Linking: 15 units @ 120 V; 26 units @ 230 V
  • Input Voltage: 100 to 240 VAC, 50/60 Hz (auto-ranging)
  • Power and Current: 40 W, 0.5 A @ 120 V, 60 Hz
    38 W, 0.3A @ 230 V, 50 Hz
  • Weight: 9.2 lb (4.2 kg)
  • Size: 13.1 x 13 x 9.4 in (335 x 332 x 241 mm)
  • Approvals: CE, FDA
  • Complies with FDA performance standards for laser products except for deviations pursuant to Laser Notice No. 50, dated June 24, 2007.

What's Included

  • Swarm Wash FX
  • Power cord
  • Hanging Bracket w/ mounting hardware
  • Warranty card
