Wash FX

The Wash FX is a rugged, punchy wash light with 6 zones of control for pixel-mapping effects. Its unique shape casts punchy colorful light everywhere, and it is tough enough for any mobile entertainer’s lifestyle. The Wash FX can be controlled manually with the control panel or with a DMX controller, and the built-in, eye-catching effects make any kind of control a breeze. For advanced pixel-mapping use ShowXpress Pixels from CHAUVET DJ.

Highlights

  • Feature-packed compact wash with eighteen 4 W tri-color LEDs

  • Built-in auto and sound programs generate eye-catching effects

  • Set up complex looks with ease using ShowXpress Pixels

  • Rugged solid metal housing is designed to withstand the rigors of the mobile entertainer

  • Save time running cables by power linking multiple units

  • Easily create custom colors, without using a controller, in standalone modes

  • Fits best in the CHS-40 VIP Gear Bag

Specifications

  • DMX Channels: 7 or 23
  • DMX Connectors: 3-pin XLR
  • Light Source: 18 LEDs (tri-color RGB) 4 W (1.4 A), 50,000 hours life expectancy
  • Strobe Rate: 0 to 20 Hz
  • Illuminance: 790 lux @ 2 m (per zone)
  • Power Linking: 11 units @ 120 V; 22 units @ 230 V
  • Input Voltage: 100 to 240 VAC, 50/60 Hz (auto-ranging)
  • Power and Current: 77 W, 1.2 A @ 120 V, 60 Hz
    75 W, 0.6 A @ 230 V, 50 Hz
  • Weight: 4.8 lb (2.2 kg)
  • Size: 8.5 x 7.1 x 10 in (215 x 180 x 255 mm)
  • Approvals: CE

What's Included

  • Wash FX
  • Power cord
  • Warranty card
