COREpar 40 USB

COREpar 40 USB produces a full spectrum of light with the unsurpassed color mixing of COB (Chip-on-Board) technology and includes a separate magnetic lens to provide the flexibility to go from an ultra-wide wash to a narrow beam in seconds. High frequency LED dimming achieves smooth LED fades and ensures a flicker-free performance in video applications. Multiple control options include DMX, master/slave and sound activation modes as well as wireless control thanks to D-Fi USB compatibility. Point-and-shoot operation of static colors and automated programs is also possible with the optional IRC-6 remote control (sold separately). The unit’s robust sit-flat housing features power and DMX outlets on the side.

Buy Now

Highlights

  • COB (Chip-on-Board) LED produces a full spectrum of light with unsurpassed color mixing

  • D-Fi™ USB compatibility for wireless Master/Slave or DMX control

  • Included magnetic Fresnel lens allows the flexibility to go from ultra-wide to narrow beam in seconds

  • Withstand the harshness of traveling from gig to gig with a robust housing

  • Sit-flat housing design hugs the floor and features power and DMX outlets on the side of the unit

  • Achieve flicker-free video operation with high-frequency LED dimming

  • Save time running cables and extension cords by power linking multiple units

  • Point-and-shoot operation of static colors and automated programs with the optional IRC-6 remote

  • Multiple control options include DMX, Master/Slave and Sound-Active modes

  • Create customized colors using the built-in LED display

  • Achieve smooth LED fading with built-in dimming curves

  • Easily transports in the optional CHS-30 VIP Gear Bag

  • Compact design easily fits inside sticks of TRUSST®

  • 40 watt COB (Chip-on-Board) LED produces a full spectrum of light with unsurpassed color mixing
  • Robust and Sit-flat housing and Magnetic Fresnel lens allows you to go from ultra-wide to narrow beam

Specifications

  • DMX Channels: 3 or 8
  • DMX Connectors: 3-pin XLR
  • Light Source: 1 COB LED (tri-color RGB) 40 W (2 A), 50,000 hours life expectancy
  • Strobe Rate: 0 to 33 Hz
  • PWM Frequency: 2,000 Hz
  • Beam Angle: 40° (without lens)
    20° (with lens)
  • Field Angle: 85° (without lens)
    28° (with lens)
  • Illuminance: 243 lux @ 2 m (without lens)
    1,660 lux @ 2 m (with lens)
  • Power Linking: 11 units @ 120 V; 21 units @ 230 V
  • Input Voltage: 100 to 240 VAC, 50/60 Hz (auto-ranging)
  • Power and Current: 47 W, 0.7 A @ 120 V, 60 Hz
    46W, 0.4 A @ 230 V, 50 Hz
  • Weight: 3.4 lb (1.6 kg)
  • Size: 5.2 x 7.4 x 9.5 in (132 x 189 x 242 mm)
  • Approvals: CE
  • Optional Controllers: IRC-6

What's Included

  • COREpar 40 USB
  • Power cord
  • Magnetic Fresnel lens
  • Warranty card
  • Quick Reference Guide
  • Hanging bracket with mounting
