CT-APP 2

CT-APP 2 is a video wall hanger built with versatility, safety and durability in mind. It mounts on the top or bottom of horizontal truss to create a hang point for video panels or other needs virtually anywhere on the truss length. It adjusts to fit any size box truss with 2” (50 mm) chords up to 20.5” x 20.5”. CT-APP2 is made of 6061 T-6 aluminum and graded steel hardware for strength and durability. It has a rated eye bolt, and orients for easy rigging connections using shackles 5/8” in size. CT-APP 2 includes load rated 360-degree wrap around style coupler clamps made of heavy-duty extruded aluminum that won’t scratch or damage truss.

Highlights

  • Mounts on top or bottom of a horizontal truss to create a hang point for video panels or other needs virtually anywhere on the truss length

  • Adjusts to fit any size box truss with 2” (50 mm) chords up to 20.5” x 20.5”

  • Includes load rated 360-degree wrap around style coupler clamps made of heavy duty extruded aluminum that won't scratch or damage truss

  • Rated eye bolt, orients for easy rigging connections using shackles 5/8” in size

  • Made of 6061 T-6 aluminum and graded steel hardware for strength and durability

  • Built with versatility, safety and durability in mind

Specifications

  • Weight:9.2 lb. (4.2 kg)
  • Dimensions:25.5 x 1.9 x 5.9 in (650 x 50
  • Load capacity: 1,100 lb. (500 kg)
  • Fits: 2 inch (50 mm) truss up to 20.5” x 20.5”

What's Included

  • CT-APP 2
