Discontinued Since 2015

EZrail RGBA

EZrail RGBA is a battery-powered, linear wash light designed for mobile applications where power is an issue. A rechargeable lithium-ion battery powers all 160 LEDs for up to 20 hours using a single charge. Perfect for area washes or uplighting, it is controllable in up to 4 sections and becomes a wireless DMX solution when paired with a D-Fi receiver.

Highlights

  • Linear, RGBA cable-free fixture includes battery power and goes anywhere light is needed

  • Achieve a run time of up to 20 hours from a single charge with the rechargeable, lithium battery

  • Enhance any event by activating built-in effects with 4 sections of control

  • Achieve rich colors and pastels with amber LEDs

  • Easily check the battery status with the built-in battery life indicator

  • Increase effects with 4 sections of individual control

  • Convenient wireless, non-DMX operation with the included IRC remote

  • Saves time setting up and tearing down by eliminating the need for power cables

  • Access built-in automated and sound-activated programs using the IRC remote or in DMX or master/slave mode

  • Easily transports in the optional CHS-60 VIP Gear Bag

  • Combine multiple units together with the CBB-6

Specifications

  • DMX Channels: 2, 4, 5, 8, 10 or 18
  • DMX Connectors: 3-pin XLR
  • Light Source: 160 LEDs (40 red, 40 green, 40 blue, 40 amber) 0.25 W (20 mA), 100,000 hours life expectancy
  • Strobe Rate: 0 to 16 Hz
  • Beam Angle: 15°
  • Field Angle: 30°
  • Illuminance: 805 lux @ 2 m
  • Power Linking: 32 units @ 120 V, 64 units @ 230 V
  • Input Voltage: 100 to 240 VAC, 50/60 Hz (auto-ranging)
  • Power and Current: 31 W, 0.2 A @ 120 V, 60 Hz
    33 W, 0.1 A @ 230 V, 50 Hz
  • Weight: 5.6 lb (2.6 kg)
  • Dimensions: 19.9 x 2.9 x 6.1 in (505 x 73 x 155 mm)
  • Approvals: CE
  • Included Controllers: IRC

What's Included

  • EZrail RGBA
