EZrail RGBA
EZrail RGBA is a battery-powered, linear wash light designed for mobile applications where power is an issue. A rechargeable lithium-ion battery powers all 160 LEDs for up to 20 hours using a single charge. Perfect for area washes or uplighting, it is controllable in up to 4 sections and becomes a wireless DMX solution when paired with a D-Fi receiver.
Images & VIDEOS
Highlights
Linear, RGBA cable-free fixture includes battery power and goes anywhere light is needed
Achieve a run time of up to 20 hours from a single charge with the rechargeable, lithium battery
Enhance any event by activating built-in effects with 4 sections of control
Achieve rich colors and pastels with amber LEDs
Easily check the battery status with the built-in battery life indicator
Increase effects with 4 sections of individual control
Convenient wireless, non-DMX operation with the included IRC remote
Saves time setting up and tearing down by eliminating the need for power cables
Access built-in automated and sound-activated programs using the IRC remote or in DMX or master/slave mode
Easily transports in the optional CHS-60 VIP Gear Bag
Combine multiple units together with the CBB-6
Specifications
- DMX Channels: 2, 4, 5, 8, 10 or 18
- DMX Connectors: 3-pin XLR
- Light Source: 160 LEDs (40 red, 40 green, 40 blue, 40 amber) 0.25 W (20 mA), 100,000 hours life expectancy
- Strobe Rate: 0 to 16 Hz
- Beam Angle: 15°
- Field Angle: 30°
- Illuminance: 805 lux @ 2 m
- Power Linking: 32 units @ 120 V, 64 units @ 230 V
- Input Voltage: 100 to 240 VAC, 50/60 Hz (auto-ranging)
- Power and Current: 31 W, 0.2 A @ 120 V, 60 Hz 33 W, 0.1 A @ 230 V, 50 Hz
- Weight: 5.6 lb (2.6 kg)
- Dimensions: 19.9 x 2.9 x 6.1 in (505 x 73 x 155 mm)
- Approvals: CE
- Included Controllers: IRC
What's Included
- EZrail RGBA
