Discontinued Since 2016

SlimBANK UV-18

SlimBANK UV-18 is a powerful blacklight with 18 high-power UV LEDs, perfect for every setting, from Halloween parties to amusement parks. Make your next event glow with the effect that is always a hit with the crowd.

Highlights

  • High-output ultraviolet LED fixture

  • Direct light where it’s needed using the included and removable barn doors

  • Achieve smooth LED fading with built-in dimming curves

  • Ideal for sound-sensitive environments due to the radiant cooling design

  • Save time running extension cords by power linking multiple units

  • Easily transports in the CHS-40 VIP Gear Bag

  • Combine multiple units using the CBB-6 mounting bracket

Specifications

  • DMX Channels: 2 or 5
  • DMX Connectors: 3-pin XLR
  • Light Source: 18 LEDs (UV) 1 W (350 mA), 50,000 hours life expectancy
  • Strobe Rate: 0 to 20 Hz
  • Coverage Angle: 65°
  • Power Linking: 22 units @ 120 V; 39 units @ 230 V
  • Input Voltage: 100 to 240 VAC, 50/60 Hz (auto-ranging)
  • Power and Current: 42 W, 0.4 A @ 120 V, 60 Hz
    46 W, 0.2 A @ 230 V, 50 Hz
  • Weight: 7.4 lb (3.4 kg)
  • Size: 15.3 x 7.7 x 7.4 in (389 x 197 x 187 mm)
  • Approvals: CE
  • Wavelength: 400 to 410 nm

What's Included

  • SlimBANK UV-18
  • Barn doors
  • Power cord
  • Hanging bracket with mounting hardware
  • Warranty card
