Discontinued Since 2015

Abyss LED 3.0

Abyss LED 3.0 is an eye-catching, multi-colored, simulated water effect light with countless uses. A high-power 15-watt white LED shines through any environment with or without fog, while two glass effect wheels and one dichroic color wheel can be controlled individually for optimal projections and effects.

Highlights

  • Eye-catching, LED effect light simulates a multicolored water effect

  • Shines through any environment with or without fog using upgraded, high-power LEDs

  • Achieve optimal projection and effects using 1 dichroic color wheel and 2 glass effect wheels

  • Easily creates a rippling effect with or without fog

  • Increase design options with independent control of effect and color wheels

  • Access non-DMX control in stand-alone mode

  • Save time running cables and extension cords by power linking multiple units

  • Fits best in the CHS-40 VIP Gear Bag

Specifications

  • DMX Channels: 2
  • DMX Connectors: 3-pin XLR
  • Colors: 5 + white, continuous scroll at variable speeds
  • Light Source: 1 LED (white) 15 W (1 A), 50,000 hours life expectancy
  • Coverage Angle: 30°
  • Power Linking: 24 units @ 120 V; 37 units @ 230 V
  • Input Voltage: 100 to 240 VAC, 50/60 Hz (auto-ranging)
  • Power and Current: 40 W, 0.3 A @ 120 V, 60 Hz
    47 W, 0.2 A @ 230 V, 50 Hz
  • Weight: 6 lb (2.7 kg)
  • Dimensions: 9.6 x 10.2 x 7.4 in (243 x 260 x 188) mm
  • Approvals: CE

What's Included

  • Abyss LED 3.0
