New

Shocker Panel FX IP

Shocker Panel FX IP instantly shifts between strobe, wash, and blinder looks as easily as it moves between indoor and outdoor events. 8 sections of bright RGB color + an intense 8-section cool white LED strip add up to endless eye candy effects from one compact IP65-rated powerhouse. Setups are fast and secure with a digital touch display for choosing dazzling built-in effect macros and setting password access, all with the press of a button. Wherever they take this rugged unit, event managers and entertainers will wow party-goers with Shocker Panel FX IP’s high output and fast transitions.

Highlights

  • Outdoor-rated versatile blinder, wash and strobe light, with compelling eye candy effects

  • Neutrik TRUE1 power input/output connections save setup time while maintaining water resistance

  • 16 controllable sections (8 RGB + 8 white) provide creative programming flexibility

  • Robust IP-rated housing repels the elements in outdoor situations

  • Password-protected and touch-sensitive digital display

  • Trigger eye-catching, built-in macros via the display or DMX

  • Integrated GORE valve allows the fixture to breathe and prevents internal humidity build-up

  • Easily transported in the optional CHS-25 VIP gear bag

Specifications

  • DMX Channels:8, 18, 34 or 47
  • DMX Connectors:3-pin XLR
  • Light Source:
    480 LEDs (tri-color) 2W, (1A), 50,000 hours life expectancy
    32 LEDs (cool white) 1.8 W (0.5 A), 50,000 hours life expectancy
  • Strobe Rate:0 to 20 Hz
  • Beam Angle:119°
  • Field Angle:158°
  • Illuminance:1,131 lux @ 2 m
  • Lumens:13,626
  • IP Rating:IP66
  • Power Linking:6 units @ 120 V; 11 units @ 230 V
  • Input Voltage:100 to 240 VAC, 50/60 Hz (auto-ranging)
  • Power and Current:
    238 W, 2 A @ 120 V, 60 Hz
    231 W, 1 A @ 230 V, 50 Hz
  • Weight:10.4 lbs (4.7 kg)
  • Size:12.9 x 5.1 x 6.8 in (330 x 130 x 173 mm)
  • Approvals:CE, ROHS, MET
  • Startup Temperature: -4 °F to 113 °F (-20 °C to 45 °C)
  • Operating Temperature: -22 °F to 113 °F (-30 °C to 45 °C)
  • Cable Length: 5 ft (1.5 m)
  • Max Output Current: 12 A (6 units @ 120 V) (11 units @ 230 V)

What's Included

  • Shocker Panel FX IP
  • Shocker Panel FX IP
  • Power cable
  • Quick Reference Guide
Save & Print

Downloads

Shocker Panel FX IP - Quick Reference Guide
Shocker Panel FX IP - User Manual
