Obey 4

It’s a compact DMX controller for LED wash lights with 3- or 4-channel modes—red, green, blue and white/amber—for easy color-mixing control. It has built-in automated, sound-activated or manual playback options and can control fixtures in four different zones—independently of each other. Its one-touch buttons of pre-mixed colors, built-in chases and strobe and dimmer controls make it perfect for a lighting novice or anyone looking for an easy way to control LED washes.

Highlights

  • Compact DMX controller designed for LED fixtures with up to 4 channels
    - Channel 1: red
    - Channel 2: green
    - Channel 3: blue
    - Channel 4: white (or amber)

  • Easily controls up to 4 separate fixtures

  • Increase effects by simultaneously operating each fixture in different playback modes with variable fade times

  • Increase flexibility with playback options that include manual RGBA/RGBW, automated and sound-activated mode

  • Playback modes:
    - Preset: 9 built-in colors
    - Chases: manually trigger automated programs
    - Color macro: manually scroll through the color spectrum
    - RGB fade: automatically scroll through the color spectrum
    - RGB fade delay: automatically scroll through the color spectrum with a small delay to each fixture
    - Auto: randomly selects different colors for each fixture

  • Increase control with adjustable audio sensitivity as well as strobe and blackout effects

Specifications

  • DMX Channels: 16
  • DMX Connectors: 3-pin XLR
  • Strobe Rate: 0 to 33 Hz
  • Input Voltage: 9 VDC, 500 mA (external power supply: 100 to 240 VAC, 50/60 Hz)
  • Weight: 3 lb (1.4 kg)
  • Size: 12.8 x 5.5 x 2.1 in (325 x 140 x 52 mm)
  • Approvals: CE

What's Included

  • Obey 4
  • External power supply
  • Quick Reference Guide
  • Warranty card
